61 Phone 716.874.9060 Toll Free 800.343.1354 Fax 716.874.4686
Crosby Painter’s Block
Block and
Tackle
• Made of light
galvanized steel
and aluminum
alloy
• Sheaves have
bronze bushings
• HS130B 6” painter’s supply
blocks for 3/4” manila rope
• Single sheave blocks
• Meets or exceeds all
requirements of ASME
B30.26 including identifica-
tion, ductility, design factor,
proof load and temperature
requirements
• Latch hook fitting
• Self lubricating
bronze bushed bearings
• Made with galvanized steel
• These blocks meet other
critical performance
requirements including
fatigue life, impact
properties and material
traceability, not addressed
by ASME B30.26
Little Mule Model 300A
Lineman’s Hoist
• Lightweight and rugged
strap hoist puller
• Includes regular hooks
• Overload protection handle
bends to warn of hazard-
ous condition and prevents
dangerous overload
• 360° swiveling hooks
equipped with latches for
positive load engagement
• Positive load holding in
all environments
• Double, interlocking
pawl mechanism
assures one pawl is
engaged at all times
• 1500 lb capacity
Little Mule Nylon
Ratcheting Hoist
• This lightweight and
rugged lineman’s hoist
is easy to operate with
an extra measure of
reliability
• Durable and portable,
corrosion resistant
• Has fiberglass handle
and polyester webbing
1 Ton Coil
Chain Hoist
• The handle and sheave hous-
ings on this hoist are made
of lightweight high-strength
heat-treated aluminum
• All working parts are fully en-
closed in the housing unit to
protect the hoist mechanism
and to cover the gearing for
worker safety
• The handle swings to either
side allowing operator to
reach overhead or below
chest level to operate hoist
Side Opening Block w/
Swivel Hook & Safety Snap
• Block and sheave con-
structed of rugged nylon
fiberglass reinforced
high dielectric material
• Reinforced 1/2” diameter
axle and swivel bearings
• Blocks are rated with 3-1
safety factor
• Lightweight and rugged
cast aluminum and
zinc alloy housings
• Corrosion resistant stainless
steel springs and shafts
• Reduced wear through
rotating shafts are mounted
on bronze bushings
• Meets minimum 4:1
designfactor and all
requirements of
ASME/ ANSI
Standard B-30.21
• All units tested at
125% of rated load
• 9’ lift and hook
• The hot stick hook
and gate latch have rings
on the latch and the hook
for use on energized lines
• Holding sticks easily ma-
neuver the latch and hooks
• 22” and 26” hook to hook
• Chain is high-strength
alloy steel
• Load hooks are forged steel
with gate type latches
• Both top and bottom
hooks swivel 360°
• Allows for unwinding
action of rope or stranded
cable under tension
• Lift: 5-1/2’
• Weight: 14 lbs
• 3” sheaves - block
can accommodate
rope up to 5/8”
diameter
• Working load limit
1,000 lbs
Klein Grip-Cleaning Brush Set
• Set of four stiff wire-bristle brushes
• Designed for cleaning Klein wire and
cable pulling grips
• Available in round and square shapes
and two lengths for efficient cleaning
of different jaw configurations
• Semi-flexible steel shafts set into
comfortable wooden handles
Hoists & Pullers
