BW Chassis Mid-Sized Ride-On Surface
Preparation Machine, Standard Model
• Features a removable dust
containment box with wheels
for ease of dumping
• One handed operation controls
for raising and lowering heads,
grinder speed and diamond/shot
engagement
• Interchangeable heads give you
the mobility and versatility to
switch applications in minutes
• The Tier 4 diesel engine is
in compliance with emission
standards in all 50 states
BW Shotblast Head Attachment for
SCB-1200 Surface Prep Machine
• Delivers a feathered blasting
edge which enables each
successive path to overlap
without excessive penetration,
omitting the “striping effect”
• The finished surface is ideal
for thin-set applications, clear
coatings, as well as having the
power to give you an aggres-
sive blast profile when needed
BW Scarifier Head Attachment for
SCB-1200 Surface Prep Machine
• Self-leveling, automatically
adjusting itself to different con-
tours of the floor or pavement
• You will achieve an accurate
removal of thin mill coatings to
1/4” overlays
• With quick change cages you
can go from steel to carbide
cutters as well as different
cage widths in minutes
BW Diamond Grinder/Polisher Head Attachment
For SCB-1200 Surface Prep Machine
• Designed for coating
removal to high gloss
polishing on totally dry
concrete
• A floating grinding head
and specially designed
shroud keeps the
machine virtually dust
free when connected
to the SCB-1200, while
removing all material off
the surface and reducing
clean-up costs and effort
Specifications:
• Non-marking tires
• 24.8 hp Kubota
D902-E3B Tier 4
diesel engine
• Hydrostat drive
• Manual steering
• 4.5 CFM compressor
Interchangeable head options:
• (BH12) Shotblast
• (DG25) Diamond
grinder/polisher
Specifications:
• Production capacity -
500 to 1000 SFH
• Cleaning path - 4” to 12”
• Width with attachment - 40”
• Weight - 420 lbs
• Aisle with min. - 54”
• Order (SCB1200K) Chassis
floor machine separately
• Faster production rates,
and a vacuum collector
system that eliminates dust
and removes all material
from the scarified surface
• Ideal for applications such
as: rubber membrane
removal, concrete milling,
line striping and bridge and
parking decks
Specifications:
• Production capacity -
1400 to 2000 SFH
• Cleaning path - 25”
• Width when attached to
machine - 52”
• Weight - 450 lbs
• Diamond life -
6000 to 14000 SF
• Order (SCB1200K) Chassis
floor machine separately
• With twin, one piece 16” rubber
mounted grinding heads that
are adjusted up and down using
air pressure, giving you infinite
adjustability
• The diamond segments can eas-
ily be interchanged from course
diamonds for coating removal to
fine resin pads for polishing
• Ideal for applications such as:
repair uneven concrete, garage
floors, industrial floors, coating
removal and concrete polishing
• Easy blast wheel
replacement eliminates
costly down time
• Ideal for applications such
as: industrial floors, line
stripes, bridge decks,
airport runways and hangers,
parking decks, steel decking
and highways
Specifications:
• Production capacity -
1800 to 2200 SFH
• Cleaning path - 12”
• Width with attachment - 36”
• Weight - 375 lbs
• Aisle width min - 54”
• Order (SCB1200K) Chassis
floor machine separately
• 1480 CFM vacuum
• 3.8 cubic ft collector capacity
• 54” blastable/aisle width min.
• 81” L x 35” W x 54” H
• 1200 lbs total weight
(Chassis Only)
• (SC12) Scarifier
• All head attachments
sold separately
Shotblasters & Surface Preparation
